1.This stitcher machine use the advantages of servo motor and driver to release sudden stop and sudden start, it replace the machine clutch and electrical clutch, also improve the stitching precision and use lift.
2. Speed is adjustable, so it is no requirement to operator’s skill.
3.Stitching head simple and easy to maintains, adopt cam revolving transmission, stitch head use alloy blade, rod use bearing connect rod, can reduce friction, prolong using life.
4.Paper feeding part use servo controller, accurate pitch of nails, no requirements to operator.
| Model | GDJ-1200 | GDJ-1400 | GDJ-1600 | GDJ-1800 |
| stapling speed | 250-400 nails/min | 250-400 nails/min | 250-400 nails/min | 250-400 nails/min |
| Stitching thickness | 3/5 ply | 3/5 ply | 3/5 ply | 3/5 ply |
| Length of strength arm | 1200mm | 1400mm | 1600mm | 1800mm |
| shape size | 1550*550*1950mm | 1850*550*1950mm | 2280*700*2100mm | 2480*700*2100mm |
| Machine weight | 430kg | 460kg | 600kg | 750kg |
